Bifacial M10 144 Cell Solar Panels by SLR Surabhi Power
Welcome to SLR Surabhi Power, your trusted provider of high-performance bifacial solar panels designed for large-scale utility and ground mount solar projects. Our RPS2MH72BDXXX series bifacial modules, featuring advanced M10 mono PERC cells, deliver exceptional efficiency and durability. With power outputs ranging from 530W to 560W and a bifaciality factor of up to 70%, these panels are engineered for maximum energy yield in diverse conditions. Ideal for projects anywhere in India, our solar panels ensure reliable, long-term performance backed by comprehensive certifications and warranties.
Why Choose Bifacial Solar Panels from SLR Surabhi Power?
Our bifacial solar panels harness energy from both sides, boosting output by up to 70% through rear-side irradiance. Built with cutting-edge technologies like multi-busbar, PERC, Ga-doped cells, half-cut design, and smart soldering, these modules excel in heavy snow, hail, and wind resistance. Here's why SLR Surabhi Power's bifacial M10 panels are the top choice for ground mount solar installations and utility-scale solar projects:
- High Efficiency & Power Output: Up to 21.68% module efficiency and 560W maximum power, perfect for maximizing ROI in solar farms.
- Enhanced Durability: Withstands up to 5400 Pascals snow load and 2400 Pascals wind load, ensuring reliability in harsh Indian climates.
- Long Lifespan: Hotspot and micro-cracking resistant with 0.45% annual degradation over 30 years for sustained performance.
- Superior Low-Light Performance: Maximizes energy generation during early mornings, late evenings, and overcast conditions — engineered to deliver consistent power across India’s varied climates, from monsoons to winter haze.
- Advanced Features: M10 bifacial mono PERC cells with 144 half-cut configuration for reduced resistance and higher yields.
- ALMM Approved: Compliant with India's Approved List of Models and Manufacturers for seamless project approvals.
- Comprehensive Certifications: ISO 9001:2015, ISO 14001:2015, and ISO 45001:2018 for quality, environment, and safety standards.
- Factory Audited & DCR Modules: Available up to 560W with positive power tolerance (0~+5W) for consistent performance.
Key Specifications of RPS2MH72BDXXX Bifacial Solar Panels
Discover the technical excellence of our 144 cell bifacial solar panels, optimized for M10 solar module efficiency and long-term reliability.
Electrical Data (STC: Irradiance 1000W/m², Cell Temperature 25°C, Air Mass AM1.5)
| Parameter | 530W | 535W | 540W | 545W | 550W | 555W | 560W |
|---|---|---|---|---|---|---|---|
| Peak Power (Pmax) - Wp | 530 | 535 | 540 | 545 | 550 | 555 | 560 |
| Power Tolerance (W) | 0 ~ +5 | 0 ~ +5 | 0 ~ +5 | 0 ~ +5 | 0 ~ +5 | 0 ~ +5 | 0 ~ +5 |
| Max Power Voltage (Vmpp) - V | 40.53 | 40.61 | 40.66 | 40.79 | 40.90 | 41.10 | 41.15 |
| Max Power Current (Impp) - A | 13.08 | 13.18 | 13.29 | 13.37 | 13.45 | 13.51 | 13.61 |
| Open Circuit Voltage (Voc) - V | 49.48 | 49.55 | 49.68 | 49.71 | 49.74 | 49.80 | 49.84 |
| Short Circuit Current (Isc) - A | 13.71 | 13.79 | 13.85 | 13.94 | 14.03 | 14.13 | 14.22 |
| Module Efficiency (ηm) - % | 20.52 | 20.71 | 20.90 | 21.10 | 21.29 | 21.48 | 21.68 |
Electrical Data (NOCT: Nominal Operating Cell Temperature)
| Parameter | Value |
|---|---|
| Maximum Power (Pmax) - Wp | 397 - 419 (varies by model) |
| Maximum Power Voltage (Vmpp) - V | 37.80 - 38.47 |
| Maximum Power Current (Impp) - A | 10.51 - 10.88 |
| Open Circuit Voltage (Voc) - V | 46.16 - 46.43 |
| Short Circuit Current (Isc) - A | 11.10 - 11.52 |
| NOCT | 43°C ±2°C |
Mechanical Data
| Feature | Details |
|---|---|
| Solar Cells | Bifacial Mono PERC, 144 Half Cut M10 Cells |
| Module Dimensions | 2278 × 1134 × 30 mm |
| Weight | 32.5 kg |
| Front Glass | 2mm High Transmission Tempered ARC Glass |
| Encapsulant | EPE / EVA |
| Rear Cover | 2mm High Transmission Glass |
| Frame | 30mm Anodized Aluminum |
| Junction Box | IP68 / IP67 Rated |
| Cable | 4.0 mm², 300mm Length (+/-), Customizable |
| Connector | MC4 Compatible |
Temperature Ratings & Protections
| Parameter | Value |
|---|---|
| Temperature Coefficient of Pmax | -0.32%/°C |
| Temperature Coefficient of Voc | -0.25%/°C |
| Temperature Coefficient of Isc | 0.06%/°C |
| Max Series Fuse Rating | 30A |
Warranties & Degradation
SLR Surabhi Power stands behind our bifacial solar modules with industry-leading guarantees:
- 12-Year Product Workmanship Warranty
- 30-Year Linear Power Warranty
- 2% First-Year Power Degradation
- 0.45% Annual Power Degradation Thereafter
With a bifaciality factor of up to 70% and 84.95% power retention over 30 years, these panels ensure cost-effective, sustainable energy for large-scale solar projects.
Packing & Logistics
| Configuration | Details |
|---|---|
| Modules per Box | 36 Pieces |
| Modules per 40’ HC Container | 720 Pieces |
Mechanical Load & Environmental Resistance
Engineered for extreme conditions, our high-efficiency bifacial panels offer:
- Snow Load Resistance: Up to 5400 Pascals
- Wind Load Resistance: Up to 2400 Pascals
- Hail & Heavy Snow Resistant: Robust frame and tempered glass for minimal weather damage
- Hotspot & Micro-Cracking Resistant: Advanced multi-busbar and half-cut technology
Performance Curves
Our M10 bifacial solar panels maintain excellent performance across irradiance levels, as shown in IV and PV curves (1000 W/m² to 200 W/m²). Contact us for detailed graphs and simulations tailored to your ground mount solar project.
Why SLR Surabhi Power for Your Solar Needs?
As a leading manufacturer of bifacial PERC solar panels, SLR Surabhi Power delivers end-to-end solutions for utility-scale solar power plants in India. Our Telangana-based projects benefit from ALMM-approved modules, factory audits, and DCR compliance. We provide:
- Customized solar panel configurations for large-scale deployments
- Expert guidance on installation, mounting slots, and grounding
- Comprehensive support from design to commissioning
- Competitive pricing and fast delivery for pan-India projects
Embrace the future of high-efficiency solar panels today! Reach out at 205, Sri Nagar Colony Rd, Sri Nagar Colony, Aurora Colony, Banjara Hills, Hyderabad, Telangana 500073, or email contact@slrsurabhi.com for a no-obligation quote.
Caution: Always read safety and installation instructions before using solar products. Specifications subject to change without notice.
